Clamp-On Harmonic Probe Model
INDIVIDUAL HARMONICS
Range: 0.2% to 300% (%THD or %DF)
Rank: Hdc (DC component), H01 to H25
Resolution: 0.1%
Accuracy: Distortion>10% and rank<H13: 5% R ±2 cts
Distortion>10% and rank>H13: 10% R ±2 cts
Distortion<10% and rank<H13: 10% R ±2 cts
Distortion<10% and rank>H13: 15% R ±2 cts
Frequency Range: Fundamental 40 Hz to 70 Hz, 25th order
Display: Digital: %THD and Individual Harmonic value (A or V)
Bar graph: True RMS (A or V)
TRANSFORMER HARMONIC DERATING FACTOR (CBEMA THDF)
Range: 0.10 to 1.00
Resolution: 0.01
Basic Accuracy: 2% R ± 2 cts
Display: Digital: THDF, Bar graph: Arms
TRANSFORMER K-FACTOR RATING
Range: 1 to 30
Resolution: 0.1
Basic Accuracy:
1 to 10: 5% R ± 2 cts
> 10: 10% R ± 2 cts
Display: Digital: %THD or K Factor, Bar graph: Arms
RIPPLE
Range: .1% to 999.9%
Resolution: 0.1%
Basic Accuracy:
2 to 99.9%: 5% R ±10 cts
100 to 999.9%: 5% R ± 2 cts
Display: Digital: % Ripple, Bar graph: DC (A or V)
