AERMEC 2502 User Manual

INSPY. 1003. 4138305_03
16
NOMINAL REFERENCE CONDITIONS
DESUPERHEATER
Outlet water temperature 45°C
Δt 5°C
TO THE TOTAL RECOVERY
Outlet water temperature 45°C
Δt 5°C
NS Vers. U.M. 1251 1401 1601 1801 2101 2401 1402 1602 1802
ENLARGED FANS (AXIAL)
Quantity
°/L
n°
666688666
A/E 66681010668
Total input power
°
kW
12 12 12 12 16 16 12 12 12
L 7,8 7,8 7,8 7,8 10,4 10,4 7,8 7,8 7,8
A 121212162020121216
E 7,8 7,8 7,8 10,4 13 13 7,8 7,8 10,4
Total input current
°
A
24 24 24 24 32 32 24 24 24
L 15,6 15,6 15,6 15,6 20,8 20,8 15,6 15,6 15,6
A 242424324040242432
E 15,6 15,6 15,6 20,8 26 26 15,6 15,6 20,8
Air fl ow rate
°
m³/h
116000 116000 110000 110000 150000 145000 116000 116000 110000
L 82000 82000 82000 82000 110000 104000 82000 82000 82000
A 110000 106000 106000 136000 180000 174000 106000 106000 144000
E
70000 74000 81500 94000 113000 118000 74000 77000 96000
FANS INVERTER (AXIAL)
Quantity
°/L
n°
666688666
A/E 66681010668
Total input power
°
kW
12 12 12 12 16 16 12 12 12
L 7,8 7,8 7,8 7,8 10,4 10,4 7,8 7,8 7,8
A 121212162020121216
E 7,8 7,8 7,8 10,4 13 13 7,8 7,8 10,4
Total input current
°
A
24 24 24 24 32 32 24 24 24
L 15,6 15,6 15,6 15,6 20,8 20,8 15,6 15,6 15,6
A 242424324040242432
E 15,6 15,6 15,6 20,8 26 26 15,6 15,6 20,8
Air fl ow rate
°
m³/h
116000 116000 110000 110000 150000 145000 116000 116000 110000
L 82000 82000 82000 82000 110000 104000 82000 82000 82000
A 110000 106000 106000 136000 180000 174000 106000 106000 144000
E
70000 74000 81500 94000 113000 118000 74000 77000 96000
EVAPORATOR (TUBE CORE)
Water contents
°/L dm
3
80 77 74 74 106 165 77 77 77
A/E dm
3
80 74 106 113 165 165 106 106 108
Water connections (VICTAULIC)
°/L
ø
4"
4"
5" 4"
A/E 5"
Electric resistor (Effi ciency/std/opt.)
NO
Water fi lter (dim/std/opt.)
Quantity N°
1
DESUPERHEATERS (PLATE HEAT) OPTIONAL
Recovered effi ciency
°
kW
65 73.5 84 96 111 123 70.5 79 89.5
L 59.5 66.5 77 90 103 113.5 65 72 81
A 70 78.5 88.2 105 116.5 133.5 76 86.5 98
E 63 73 82.5 98 108 124 68 78.5 91
Quantity all no. 1 2
Water fl ow rate
°
l/h
11180 12642 14448 16512 19092 21156 12126 13588 15394
L 10234 11438 13244 15480 17716 19522 11180 12384 13932
A 61060 69316 76196 93396 103544 117648 67596 76540 88064
E 61060 69316 76196 93396 103544 117648 67596 76540 88064
Pressure drop of the exchanger all kPa 4
Water connections (VICTAULIC) diam
2"
Desuperheater weight All kg 30 30 30 40 50 60 40 40 40
HEAT RECOVERY (PLATE HEAT) OPTIONAL
Recovered effi ciency
°
kW 355 403 443 543 602 684 393 445 512
L
A
E
Quantity
all
n° 1
Water fl ow rate l/h 61060 69316 76196 93396 103544 117648 67596 76540 88064
Pressure drop of the exchanger kPa 44 57 69 51 62 65 54 69 45
Water connections (VICTAULIC) Ø
4"
PUMP/S No. 1 - 2 x circuit OPTIONAL
PUMPS
PA PC PE PG PJ
Input power kW 4 5,5 7,5 9,2 11
Input current A
5,5 7,5 10 12,5 15
Weight kg 109 117 121 140 148
Water connections (VICTAULIC) Ø
According to the fitted evaporator
