AERMEC 2502 User Manual

INSPY. 1003. 4138305_03
17
Sound power
Aermec determines the sound power value on the
basis of measurements taken in accordance with
standard 9614-2, in compliance with the Eurovent
certification.
Sound pressure
Sound pressure in an unrestricted range on a reflec-
tive plane (directional fact. Q=2), 10m away from
the unit external surface, complying with ISO 3744.
NS Vers. U.M. 1251 1401 1601 1801 2101 2401 1402 1602 1802
EXPANSION TANK
Capacity
-
dm
3
25
Calibration pressure Bar 1.5
Quantity n° 2
SOUND DATA
Sound power
°
dB(A)
94 95 97 97 98 98 96 97 97
L 868789899090888989
Sound pressure
° 61,8 62,8 64,8 64,8 65,6 65,6 63,8 64,8 64,8
L 53,8 54,8 56,8 56,8 57,6 57,6 55,8 56,8 56,8
Sound power
A 949597979898969797
E 868789899090888989
Sound pressure
A 61,8 62,8 64,8 64,6 65,5 65,5 63,8 64,8 64,6
E
53,8 54,8 56,8 56,6 57,5 57,5 55,8 56,8 56,6
DIMENSIONS°/L
Height
ALL
mm
2450 2450 2450 2450 2450 2450 2450 2450 2450
Width 2200 2200 2200 2200 2200 2200 2200 2200 2200
Depth 3780 3780 3780 3780 4770 4770 3780 3780 3780
Weight when empty
Kg
2910 3060 3150 3650 4230 4570 3250 3270 3460
Weight when empty with desuperheater 2940 3090 3180 3690 4280 4630 3290 3310 3500
Weight when empty with total heat recovery 3130 3280 3370 3914 4516 4889 3470 3490 3724
Weight during operation
2990 3137 3224 3724 4336 4735 3327 3347 3537
DIMENSIONS A/E
Height
ALL
mm
2450 2450 2450 2450 2450 2450 2450 2450 2450
Width 2200 2200 2200 2200 2200 2200 2200 2200 2200
Depth 3780 3780 3780 4770 5750 5750 3780 3780 4770
Weight when empty
Kg
3050 3230 3250 4330 4920 5150 3420 3560 3900
Weight when empty with desuperheater 3080 3260 3280 4370 4970 5210 3460 3500 3940
Weight when empty with total heat
recovery
3270 3450 3470 4594 5206 5469 3640 3780 4164
Weight during operation
3130 3304 3356 4443 5085 5315 3526 3666 4008
