AERMEC 2502 User Manual

INSPY. 1003. 4138305_03
22
NS Vers. U.M.
3602 3902 4202 4502 4802 5002 5202 5402 5702
ENLARGED FANS (AXIAL)
Quantity
°/L
n°
12 14 14 16 16 16 16 18 20
A/E 16 18 18 20 20 20 20 20 20
Total input power
°
kW
24 28 28 32 32 32 32 36 40
L 15.6 18.2 18.2 20.8 20.8 20.8 20.8 23.4 26
A 323636404040404040
E 20.8 23.4 23.4 26 26 26 26 26 26
Total input current
°
A
48 56 56 64 64 64 64 72 80
L 31.2 36.4 36.4 41.6 41.6 41.6 41.6 46.8 52
A 647272808080808080
E 41.6 46.8 46.8 52 52 52 52 52 52
Air fl ow rate
°
m³/h
220000 260000 255000 295000 290000 297000 304000 324000 360000
L 164000 192000 186000 214000 208000 212000 216000 240000 267000
A 272000 316000 310000 354000 348000 346000 346000 346000 346000
E 188000 207000 212000 231000 236000 254000 272000 283500 295000
FANS INVERTER (AXIAL)
Quantity
°/L
n°
12 14 14 16 16 16 16 18 20
A/E 16 18 18 20 20 20 20 20 20
Input power
°
kW
24 28 28 32 32 32 32 36 40
L 15.6 18.2 18.2 20.8 20.8 20.8 20.8 23.4 26
A 323636404040404040
E 20.8 23.4 23.4 26 26 26 26 26 26
Input current
°
A
48 56 56 64 64 64 64 72 80
L 31.2 36.4 36.4 41.6 41.6 41.6 41.6 46.8 52
A 647272808080808080
E 41.6 46.8 46.8 52 52 52 52 52 52
Air fl ow rate
°
m³/h
220000 260000 255000 295000 290000 297000 304000 324000 360000
L 164000 192000 186000 214000 208000 212000 216000 240000 267000
A 272000 316000 310000 354000 348000 346000 346000 346000 346000
E 188000 207000 212000 231000 236000 254000 272000 283500 295000
EVAPORATOR (TUBE CORE)
Water contents
°/L
dm
3
74+74 74+106 74+165 106+165 165+165 165+200 200+200 200+200 200+200
A/E 113 +113 113+165 113+165 165+165 165+165 165+188 188+188 188+188 188+188
Water connections (VICTAULIC)
°/L
ø
4"+4" 4"+4" 4"+5" 4"+5" 5"+5" 5"/6" 6"/6" 6"/6" 6"/6"
A/E 4"+4" 4"+5" 4"+5" 5"+5" 5"+5" 5"/6" 6"/6" 6"/6" 6"/6"
Electric resistor (Effi ciency/std/opt.) NO
Water fi lter (dim/std/opt.) NO
Quantity n° 2
DESUPERHEATERS (PLATE HEAT) OPTIONAL
Recovered effi ciency
°
kW
192 207 219 234 246 264 276 288 303
L 180 193 203.5 216.5 227 244 257 270 283
A 223.2 221.2 238.2 249.8 266.5 281.2 298 314.7 326.2
E 195.5 205.5 222 232 248.5 263 278 293 303
Quantity all n° 222222222
Water fl ow rate
°
l/h
33024 35604 37668 40248 42312 45408 47472 49536 52116
L 30960 33196 35002 37238 39044 41968 44204 46440 48676
A 38390 38046 40970 42966 45838 48366 51256 54128 56106
E 33626 35346 38184 39904 42742 45236 47816 50396 52116
Pressure drop of the exchanger
°
kPa
444445667
L 444445566
A 444445788
E 444445677
Water connections (VICTAULIC) Ø
2"
Desuperheater weight All kg 80 100 90 110 120 120 120 120 120
HEAT RECOVERY (PLATE HEAT) OPTIONAL
Recovered effi ciency
°
kW
1084 1144 1226 1285 1367 1428 1527 1626 1686
L 1084 1144 1226 1285 1367 1428 1527 1626 1686
A 1084 1144 1226 1285 1367 1428 1527 1626 1686
E 1084 1144 1226 1285 1367 1428 1527 1626 1686
Quantity All n° 222222222
Water fl ow rate All l/h 186448 196768 210872 221020 235124 245616 262644 279672 289992
Pressure drop of the exchanger All kPa 51 56 58 63 65 65 62 70 76
Water connections (VICTAULIC) Ø
4"
Weight All kg
528 550 583 605 638 669 680 680 680
PUMP/S No. 1 - 2 x circuit OPTIONAL
PUMPS
PA PC PE PG PJ
Input power kW 4 5,5 7,5 9,2 11
Input current A
5,5 7,5 10 12,5 15
Weight kg 109 117 121 140 148
Water connections (VICTAULIC) diam
According to the fitted evaporator
NOMINAL REFERENCE CONDITIONS
DESUPERHEATER
Outlet water temperature 45°C
Δt 5°C
TO THE TOTAL RECOVERY
Outlet water temperature 45°C
Δt 5°C
