EXPANSION TANK
Capacity
-
dm
3
25
Calibration pressure Bar 1.5
Quantity n° 4
SAFETY VALVE
Calibration bar 6 6 6666666
Quantity no.
2 + 2 2 + 2 2 + 2 2 + 2 2 + 2 2 + 3 3 + 3 3 + 3 3 + 3
SOUND DATA
Sound power
°
dB(A)
99 100 100 100 100 101 101 101 101
L 929292929293939393
Sound pressure
°
dB(A)
66,4 67,3 67,3 67,2 67,2 68,1 68,0 68,0 68,0
L 59,4 59,3 59,3 59,2 59,2 60,1 60,0 60,0 60,0
Sound power
A
dB(A)
99 100 100 100 100 101 101 101 101
E 929292929293939393
Sound pressure
A
dB(A)
66,2 67,1 67,1 67,0 67,0 68,0 68,0 68,0 68,0
E
59,2 59,1 59,1 59,0 59,0 60,0 60,0 60,0 60,0
DIMENSIONS°/L
Height ALL
mm
2450 2450 2450 2450 2450 2450 2450 2450 2450
Width 2200 2200 2200 2200 2200 2200 2200 2200 2200
Depth 7160 8150 8150 9140 9140 10120 11100 11100 11100
Weight when empty
Kg
7280 7830 8180 8750 9090 9360 10100 10200 10350
Weight when empty with desuper-
heater
7360 7930 8270 8860 9210
Weight when empty with total heat
recovery
7808 8380 8763 9355 9728 10029 10780 10880 11030
Weight during operation
7428 8010 8419 9021 9420 9725 10500 10600 10750
DIMENSIONS A/E
Height
mm
2450 2450 2450 2450 2450 2450 2450 2450 2450
Width 2200 2200 2200 2200 2200 2200 2200 2200 2200
Depth 9140 10120 10120 11100 11100 11100 11100 11100 11100
Weight when empty
Kg
8610 9180 9410 9820 10200 10450 10750 10800 10850
Weight when empty with desuper-
heater
8690 9280 9500 9930 10320 10570 10870 10920 10970
Weight when empty with total heat
recovery
9138 9730 9993 10425 10838 11119 11430 11480 11530
Weight during operation 8836 9458 9688 10150 10530 10803 11126 11176 11226
Sound power
Aermec determines the sound power value on
the basis of measurements taken in accordance
with standard 9614-2, in compliance with the
Eurovent certification.
Sound pressure
Sound pressure in an unrestricted range on a reflec-
tive plane (directional fact. Q=2), 10m away from
the unit external surface, complying with ISO 3744.
