1918.01. 6755441_03
ANL-ANLH 020-202
EN
3.11. ANL 102 ÷ 202 
102
515
138
Ø 28 G
Ø 15.88 L
80 1590 80
Ø 9
40
20
750
Gx
Gy
1450
750
Ø 34
A
D
CB
Mod. A B C D
VT15 50 30 28,5 M10
WARNING
For the weight distribution refer to
versions "° | H"
A
C
B
D
