AERMEC ANL152HQ - Anl 030 ÷ 040 Version °|P|H|Hp

10 18.01. 6755441_03
ANL-ANLH 020-202
EN
3.2. ANL 030 ÷ 040 
A
D
CB
Mod. A B C D
VT9 40 30 23 M8
1000
194
97
354
310
900
69
113
IN 1”¼
OUT 1”¼
OUT 1”¼
IN1”¼
650
330
Ø 9
895
122,50 122,50
Gx
Gy
ANL MOD. VERS. WEIGHTS C. OF G. A B C D KIT
VTGy Gx % % % %
030 °/H ° 86 183 336 30% 33% 18% 19% 9
030 °/H P 91 180 327 31% 33% 18% 19% 9
040 °/H ° 86 183 336 30% 33% 18% 19% 9
040 °/H P 91 180 327 31% 33% 18% 19% 9
AC
B
D
