AERMEC MVA - Technical Data

5
Cooling (EN-14511 e EN-14825)
Indoor Air Temperature 27°C D.B./ 19 W.B.; Outdoor Air Temperature 35°C; Max Speed; Pipe Length 5m
Heating (EN-14511 e EN-14825)
Indoor Air Temperature 20°C D.B.; Outdoor Air Temperature 7°C D.B./ 6°C W.B.; Max Speed; Pipe Length 5m
3. TECHNICAL DATA
MVA1000V MVA1400V
Cooling capacity kW 10 14
Heating capacity kW 11 15
Total input power W 200 200
Dehumidifying volume l/h
Fan type Type Centrifugal
Air flow
indoor units
Min
m3/h
1400 1400
Med 1600 1600
Max 1850 1850
Sound pressure
indoor units
Min
db(A)
46 46
Med 48 48
Max 50 50
Sound power
indoor units
Min
db(A)
56 56
Med 58 58
Max 60 60
Connection pipe (Liquid)
mm (inch)
9,52 9,52
Connection pipe (GAS) 15,9 15,9
Diameter condensate drain mm 31 31
Dimensions
indorr units
Height
mm
1870 1870
Width 580 580
Depth 400 400
Shipping
dimensions
Height 545 545
Width 2083 2083
Depth 738 738
Weight Indoor Unit
Net
kg
54 57
Gross 74 77
Power supply Type
220-240V~50Hz
208-230V~60HZ
