Steps to fix the shutter:
1. Unscrew the screw of the damper selected.
2. After passing the refrigerator lines and other connections through the
damper, secure it in the desired position by tightening the screw.
1
2
Proceedings to determine the anti-tip device:
1. Unscrew the screw on top of the unit.
2. Place the tilt lock and secure it with the screw removed in the prece-
ding paragraph.
3. attach the security cable to a hook (not supplied) attached properly
to the wall.
1
2
3
