AERMEC PXL 2 E - DIP Switch Configuration Diagram; SW1 and SW2 Function Mapping

ON
OFF
123
4
5
Ventilazione continua
Continuous ventilation
Ventilation continue
Kontinuierliche belüftung
Impianto senza valvola
Set up without valve
Installation sans vanne
Anlange ohne Ventil
ON
OFF
ON
OFF
ON
Ventilazione termostatata
Thermostat controlled ventilation
Ventilation thermostatée
Thermostatgesteuerte belüftung
Impianto con valvola
Set up with valve
Installation avec vanne
Anlage mit Ventil
Sw1
Selettore temperatura (B) posizione centrale = 23°C (Comfort caldo)
Temperature selector (B) central position = 23°C (Comfort Heat)
Selecteur temperature (B) position central =23°C (Comfort Chaude)
Temperaturwähler (B) mittlere Position = 23° C (Comfort Warm)
Selettore temperatura (B) posizione centrale =20°C (Comfort caldo)
Temperature selector (B) central position = 20° C (Comfort Heat)
Selecteur temperature (B) position central = 20°C (Comfort Chaude)
Temperaturwähler (B) mittlere Position = 20°C (Comfort Warm)
ON
*
*
*
*
Sw2
Sw2 Pretarato in fabbrica
Sw2 Pre-set in factory
Sw2 Réglé en usine
Sw2 Werkseting vorgerüstet
ON
OFF
*
7
6
= Impostazioni di fabbrica • Factory settings • Configurations de l'usine • Werkseinstellung
SW1
SW2
12
CONFIGURAZIONE DIP SWITCH • DIP SWITCH CONFIGURATION
CONFIGURATION DIP SWITCHES • DIP SCHALTER-KONFIGURATION
Fig. 10
29
+
-
70
11
7.5
9.5
4
9.5
7.5
4
11
97.5
62
10.5
145
Fig. 11
