ACCESSORY COMPATIBILITY
Notes:
- Attention: for safety reasons, it is recommended not to position the FTF “Pocket Filter” module near the PBE module
- Attention: in the presence of accessory PBE, the unit flow rate must not drop below 60% of the normal flow rate provided
- The M3S accessory must be coupled with the VRF accessory
- The VRF accessory can be selected even if not coupled with the M3S accessory
PBEx
PLENUM CON
BATTERIA
ELETTRICA
SSLx
SILENZIATORI
PMCx
PLENUM
CHIUSO
PMMx
PLENUM CON
MANDATE
CIRCOLARI
SASx
SERRANDA
GMDx
GRIGLIA DI
MAN DATA
M2Sx
CAMERA DI
MISCELA 2
SERRANDE
SSLx
SILENZIATORI
2 SERRANDE
ASPIRAZIONE
UNITA’
MANDATA
FTFx
FILTRI A
TASCHE
PBEx
PLENUM CON
BATTERIA
ELETTRICA
SSLx
SILENZIATORI
oppure
versione 4 , 6
versione E
accessorio B1R, B2R
accessorio B1R, B2R
oppure
versione 4 , 6
versione E
FPIx
PORTAFILTRO
FTFx
FILTRI A
TASCHE
PMCx
PLENUM
CHIUSO
PMMx
PLENUM CON
MANDATE
CIRCOLARI
SASx
SERRANDA
GMDx
GRIGLIA DI
MAN DATA
FTFx
FILTRI A
TASCHE
M3Sx
CAMERA DI
MISCELA 3
SERRANDE
VRFx
SEZIONE
VENTILANTE
DI RIPRESA
FTFx
FILTRI A
TASCHE
SSLx
SILENZIATORI
GAPx
GRIGLIA DI
ASPIRAZIONE
SASx
SERRANDA
3 SERRANDE
SSLx
SILENZIATORI
GAPx
GRIGLIA DI
ASPIRAZIONE
SASx
SERRANDA
FTFx
FILTRI A
TASCHE
S2Zx
CAMERA DI
MISCELA 2
SERRANDE FRONTALI
FLUSSO UNICO O
2 SERRANDE FRONTALI
Below are the diagrams representing the different ways of coupling the
accessories to the base units. The selection of a intake/flow accessory
module precludes the choice of otheraccessories in the vertical direction
but not in the horizontal. For example: if the “SAS” accessory is provided
in intake, that accessory will not be compatible with the accessory “S2Z”
but it can be combined with the “SSL” and “FTP” accessory. The diagrams
respectively represent a horizontal and vertical configuration of the unit.
The diagrams may not be exhaustive of available combinations: however,
we recommend to follow the rules set-out and possibly contact the
AERMEC Sales Technical Dept.
Horizontal
INTAKE
SINGLE FLOW OR 2 FRONT DAMPERS
3 DAMPERS 2 DAMPERS
UNIT FLOW
INTAKE GRID
INTAKE GRID
DAMPER
DAMPER
SILENCERS
SILENCERS
BAG FILTERS
version 4, 6
version E
or
or
FILTER SUPPORT
accessory B1R, B2R
accessory B1R, B2R
MIXING
CHAMBER 2
DAMPERS
PLENUM WITH
ELECTRIC COIL
PLENUM WITH
ELECTRIC COIL
PLENUM
CLOSED
FLOW GRID
FLOW GRID
PLENUM WITH
CIRCULAR FLOWS
PLENUM WITH
CIRCULAR FLOWS
PLENUM
CLOSED
DAMPER
DAMPER
BAG FILTERS
BAG FILTERS
RETURN
VENTILATING
SECTION
MIXING
CHAMBER 3
DAMPERS
BAG FILTERS
SILENCERS SILENCERS
SILENCERS
BAG FILTERS
MIXING CHAMBER 2
FRONT DAMPERS
version 4, 6
version E
