ACCESSORY COMPATIBILITY
ACCESSORY WEIGHTS
Taglie
DESCRIPTION
9 11 15 19 24 33 40 50
intake grid GAPx 2 2 2 3 3 3 4 4
Flow grid with double adjustable louvers GMDx 3 3 4 4 4 4 6 6
Intake damper SASx 5 5 7 9 13 13 18 18
2-opposite area damper 70-30 S2Zx 5 5 8 10 14 14 19 19
Mixing chamber 2 dampers M2Sx 23 23 35 37 43 43 69 69
Mixing chamber 3 dampers M3Sx 27 27 31 40 50 50 99 99
Soft bag lters section FTFx 20 20 27 29 39 39 70 70
All closed ow plenum PMCx 15 15 20 22 28 28 54 54
Return ventilating section with lter VRFx 19 22 27 36 43 55 61 62
Plenum with multiple circular ows PMMx 16 16 21 23 29 29 56 56
Silencers section SSLx 25 25 33 37 47 47 80 80
2-Stage electric post-heating coil plenum PBEx 16 16 21 23 29 30 57 58
1 R Water post-heating coil B1Rx 12 12 15 16 21 21 27 27
2 R Water post-heating coil B2Rx 13 13 17 19 25 25 33 33
Flat lter section with lower intake
FPIx 3 3 5 5 6 6 7 7
The weight of the accessories is expressed in Kg.
Below are the weights relating to the TA unit accessories.
For more information, please contact the AERMEC S.p.a. Sales Technical Dept.
Accessory compatibility
TA 09 TA 11 TA 15 TA 19 TA 24 TA 33 TA 40 TA 50
M2S M2S1 M2S1 M2S2 M2S3 M2S4 M2S4 M2S5 M2S5
M3S M3S1 M3S1 M3S2 M3S3 M3S4 M3S4 M3S5 M3S5
FTF FTF1 FTF1 FTF2 FTF3 FTF4 FTF4 FTF5 FTF5
B1R B1R1 B1R1 B1R2 B1R3 B1R4 B1R4 B1R5 B1R5
B2R B2R1 B2R1 B2R2 B2R3 B2R4 B2R4 B2R5 B2R5
VCT (2 way) VCT 102 VCT 102 VCT 202 VCT 202 VCT 202 o 402 VCT 402 o402P VCT 402P VCT 402P
VCT (3 way) VCT 103 VCT 103 VCT 202 VCT 403 o403P VCT 403 o 403P - - -
VCTA230 • • • • • • • •
VCTA24M • • • • • • • •
PBE PBE1 PBE2 PBE3 PBE4 PBE5 PBE6 PBE7 PBE8
SSL SSL1 SSL1 SSL2 SSL3 SSL4 SSL4 SSL5 SSL5
S2Z S2Z1 S2Z1 S2Z2 S2Z3 S2Z4 S2Z4 S2Z5 S2Z5
VRF VRF1 VRF2 VRF3 VRF4 VRF5 VRF6 VRF7 VRF8
PMM PMM1 PMM1 PMM2 PMM3 PMM4 PMM4 PMM5 PMM5
PMC PMC1 PMC1 PMC2 PMC3 PMC4 PMC4 PMC5 PMC5
SAS SAS1 SAS1 SAS2 SAS3 SAS4 SAS4 SAS5 SAS5
GMD GMD1 GMD1 GMD2 GMD3 GMD4 GMD4 GMD5 GMD5
GAP GAP1 GAP1 GAP2 GAP3 GAP4 GAP4 GAP5 GAP5
FPI FPI1 FPI1 FPI2 FPI3 FPI4 FPI4 FPI5 FPI5
PX • • • • • •(2) •(2) •(2)
WMT 05 • •(1) •(1) •(2) •(2) •(2) •(2) •(2)
WMT 06 • •(1) •(1) •(2) •(2) •(2) •(2) •(2)
WMT 10 • •(1) •(1) •(2) •(2) •(2) •(2) •(2)
(1) SIT3 is to be used and the 2A fuse is to be replaced with a 4A fuse
(2) Provide time delay relays, one for each speed
- Not available
