AERMEC TA 09 User Manual

12
PERFORMANCE SPECIFICATIONS
Model ver. TA09 TA11 TA15 TA19 TA24 TA33 TA40 TA50
Main coil rows 4 6 4 6 4 6 4 6 4 6 4 6 4 6 4 6
Nominal air flow
rate (1)
H/V m³/h 800 800 1100 1100 1500 1500 1900 1900 2400 2400 3300 3300 4000 4000 5000 5000
H/V l/s 222 222 306 306 417 417 528 528 667 667 917 917 1111 1111 1389 1389
Useful static
pressure
H/V Pa 145 131 290 265 176 158 240 224 211 199 245 224 248 234 153 131
Number of
electric fans
H/V n 1 2 2 1 1 2 2 2
Input power H/V W 249 310 380 610 835 815 980 1280
2-Pipe system yields
Cooling capacity
(2)
total H/V kW 4,2 5,1 5,7 6,7 8,7 11,7 12,4 15,5 17,3 20,6 21,7 26,3 27,2 33,5 31,8 39,6
sensitive H/V kW 3,5 3,4 4,2 4,7 6,2 7,5 8,3 9,8 11,2 12,8 14,3 16,6 18,0 20,9 21,3 25,0
Water flow rate H/V l/h 722 868 980 1152 1496 2012 2132 2666 2975 3543 3732 4523 4678 5761 5469 6810
Pressure drops H/V kPa 6 4 6 6 7 15 12 28,5 16 27 23 41 11 31 15 42
Heating capacity 70°/60° C H/V kW 10,4 11,4 13,3 14,8 19,1 21,4 24,7 27,4 34,1 35,6 41,9 46,6 52,8 58,3 62,8 72,8
Water flow rate 70°/60° C H/V l/h 894 976 1139 1273 1642 1838 2124 2356 2932 3058 3603 4005 4538 5013 5400 6260
Pressure drops 70°/60° C H/V kPa 5 4 8 7 7 16 10 23 13 21 19 34 10 22 13 30
1 Row water coil 4-pipe system yields
Heating capacity 70°/60° C H/V kW 4,4 5,1 8,2 10,6 14,2 16,3 22,4 24,7
Water flow rate 70°/60° C H/V l/h 378 435 705 907 1221 1403 1926 2124
Pressure drops 70°/60° C H/V kPa 9 7 21 13 14 17 21 25
2 Rows water coil 4-pipe system yields
Heating capacity 70°/60° C H/V kW 3,9 8,5 12,7 16,0 21,7 26,7 34,8 40,0
Water flow rate 70°/60° C H/V l/h 333 731 1092 1371 1866 2291 2988 3439
Pressure drops 70°/60° C H/V kPa 8 11 13 14 18 26 18 23
Electric coil
Electric coil
capacity
H/V kW 4 6 8 10 12 16 20 24
Electric coil
stages
H/V n° 2 2 W 2 2 2 2 2
Electric power
supply
H/V V/Ph/Hz 400 V -3 - 50 Hz
Filters available
H/V G4 G4 G4 G4 G4 G4 G4 G4
H/V F6 F6 F6 F6 F6 F6 F6 F6
Sound power
level
H/V dB(A) 62 66 67 72 74 75 76 79
1 At maximum fan speed
2 Air temperature (in) 27°C d.b. 47% R.H.; Water temperature (in/out) 7°C / 12°C
This unit is designed for a maximum amount of outdoor air of 10% of the total declared airow
