39
HEATING POWER
HEATING 4 ROWS COIL
TA 09
Ta B.S. [°C]
16 18 20 22 24
Tw(in) Ph Ph Ph Ph Ph
in dt [W] [W] [W] [W] [W]
70
5 11662 11157 10660 10170 9687
10 11395 13206 10400 9910 9420
15 11083 10578 10081 9583 9101
65
5 10556 10059 9569 9079 8604
10 10274 9784 9294 8804 8321
15 9940 9442 8945 8455 7973
60
5 9791 9294 8789 8299 7809
10 9153 8663 8180 7698 7223
15 8789 8299 7809 7319 6837
50
5 7230 6748 6273 5805 5345
10 6896 6414 5931 5456 4981
15 6458 5961 5464 4966 4469
45
5 6117 5642 5174 4706 4246
10 5746 5271 4788 4313 3830
15 5248 4743 4231 3704 3170
40
5 4996 4528 4068 3600 3147
10 4588 4098 3615 3125 2620
15 3979 3437 2784 1811 1039
TA 15
Ta B.S. [°C]
16 18 20 22 24
Tw(in) Ph Ph Ph Ph Ph
in dt [W] [W] [W] [W] [W]
70
5 21418 20491 19577 18677 17791
10 20927 24253 19100 18200 17300
15 20354 19427 18514 17600 16714
65
5 19386 18473 17573 16673 15801
10 18868 17968 17069 16169 15283
15 18255 17341 16428 15528 14642
60
5 17982 17069 16142 15242 14342
10 16810 15910 15024 14138 13265
15 16142 15242 14342 13442 12556
50
5 13279 12393 11520 10661 9816
10 12665 11779 10893 10020 9148
15 11861 10947 10034 9121 8207
45
5 11234 10361 9502 8643 7798
10 10552 9680 8793 7921 7035
15 9639 8712 7771 6803 5821
40
5 9175 8316 7471 6612 5780
10 8425 7525 6639 5740 4812
15 7307 6312 5112 3326 1909
TA 11
Ta B.S. [°C]
16 18 20 22 24
Tw(in) Ph Ph Ph Ph Ph
in dt [W] [W] [W] [W] [W]
70
5 14802 14161 13530 12908 12296
10 14463 16761 13200 12578 11956
15 14067 13426 12795 12164 11551
65
5 13398 12767 12145 11523 10920
10 13040 12418 11796 11174 10562
15 12616 11985 11353 10731 10119
60
5 12427 11796 11155 10534 9912
10 11617 10995 10383 9770 9167
15 11155 10534 9912 9290 8678
50
5 9177 8564 7961 7368 6784
10 8753 8140 7528 6925 6322
15 8197 7566 6934 6303 5672
45
5 7764 7161 6567 5973 5389
10 7293 6690 6077 5474 4862
15 6661 6021 5370 4701 4023
40
5 6341 5747 5163 4570 3995
10 5823 5201 4588 3967 3326
15 5050 4362 3533 2299 1319
TA 19
Ta B.S. [°C]
16 18 20 22 24
Tw(in) Ph Ph Ph Ph Ph
in dt [W] [W] [W] [W] [W]
70
5 27697 26498 25317 24153 23007
10 27062 31364 24700 23536 22373
15 26322 25123 23942 22761 21615
65
5 25070 23889 22725 21562 20433
10 24400 23237 22073 20909 19764
15 23607 22426 21244 20081 18935
60
5 23254 22073 20874 19711 18547
10 21738 20575 19429 18283 17154
15 20874 19711 18547 17383 16237
50
5 17172 16026 14898 13787 12694
10 16379 15233 14087 12958 11830
15 15338 14157 12976 11795 10613
45
5 14527 13399 12288 11178 10085
10 13646 12517 11372 10243 9097
15 12465 11266 10049 8798 7528
40
5 11865 10754 9661 8551 7475
10 10896 9732 8586 7422 6223
15 9450 8163 6611 4302 2468
The heating power yielded by the coils (standard or larger) are stated in
table format and are referred to the maximum speed, based on the water
ow and on the dierence of temperature between water entering and air
entering.
NB: The yield values marked in bold indicate the nominal value.
Key:
Tw(in) = Inlet water temperature
Ta D.B. [°C] = Inlet water temperature with dry bulb
Ph [W] = Heating power yielded
