22/10 – 5905355_00 19
8 ELECTRICAL CHARACTERISTICS
NOT USED
NOT USED
OUTPUT TRIAC
OUTPUT TRIAC
GND
A (T+) RS485
B (T-) RS485
C1 C0
I/O Function Electrical characteristics
M1_1 Power supply terminal L/AC1 Vin: 230 Vac, 50/60 Hz, Imax: 1 A
M1_2 Power supply terminal N/AC2 Vin: 230 Vac, 50/60 Hz, Imax: 1 A
M1_3 Terminal for earth reference PE
M2_1 Triac output terminal for load control Vin: 230 Vac, 50/60 Hz, Imax: 1 A
M2_2 Triac output terminal for load control Vin: 230 Vac, 50/60 Hz, Imax: 1 A
M3_1 Uart RS485 serial terminal A (T+) V max −9 [V] ÷ +14 [V]
M3_2 Uart RS485 serial terminal B (T-) V max −9 [V] ÷ +14 [V]
M3_3 Uart RS485/TTL Slave serial terminal GND
