36 22/10 – 5905355_00
BEISPIEL FÜR EINEN ELEKTRISCHEN ANSCHLUSS
Nachstehend nden Sie den elektrischen Anschlussplan, der für alle VMF-FMD-Thermostate verwendet werden kann:
23OV 50Hz
L
N
IG
VMF-FMD
GND
A
B
MODBUS
RTU RS485
C1
C0
