Aeroflex PSD60-2R - Specifications and Measurement Ranges

Aeroflex Operation Manual
PSD60-2R – REV 01 – SEPTEMBER 30, 2010 – PAGE 1-5
1.3 UNPACKING AND INSPECTING EQUIPMENT
Exercise extreme care when unpacking the unit. Make a visual inspection of the unit for evidence of damage
incurred during shipment. If a claim for damage is to be made, save the shipping container to substantiate the
claim. When the equipment has been unpacked, return all the packing material to the container for future use in
storing or shipping of the equipment. Remove any protective covers from connectors before using the equipment.
Replace any covers on the connectors after using the PSD60-2R.
1.4 SPECIFICATIONS
Environmental Specifications
The environmental specifications are as follows:
Size: 16.5 cm H x 35.6 cm W x 26.9 cm D (6.5” H x 14” W x 10.6” D)
Mass (Weight): 5.4 kg (12 lbs.)
Container: High-impact plastic
Operating Temperature: -25 C to +55 C
Relative Humidity (Non-Condensing):
80% maximum for  30 C
Decrease linearly to 50% at 40 C
40 C  50% maximum  55 C
Operating Altitude:  2 000 m
IEC Overvoltage Category: II
Pollution Degree: 2
Intrinsic Safety: 1 J @ 0.02 F (normal operation)
Measurement
Range
Capacitance Measurement Range
Range
Resolution
Low 0 - 199.99 F 0.01 F
Mid 200 - 1999.9 F 0.1 F
High 2,000 - 19,999 F 1 F
20.00K - 39.99 KF 10 F
DTF 0 - 19,999 F 1 F
20.00K - 39.99 KF 10 F
Resistance Measurement Mode (9 ranges) 10 m to 1999 M
(optional) 2000 M to 19999 M
Measurement
Accuracy
AC Capacitance:
Mode A Greater of +/- 0.1% of reading or 0.05 F from 0 – 39.99 KF at
0 Phase Shift.
Mode B Greater of +/- 0.1% of reading or 0.05 F from 0 – 39.99 KF
at 0 to 359 Phase Shift.
DTF Greater of +/- 0.1% of reading or 2 F
Resistance: Greater of 2% of reading or 0.1 ohm
+/- 5% of reading for R > 2000 M ohm
