AEV BSM Evolution USB User Manual

BSM Evolution USB - Compact ON AIR console
AEV Broadcast Srl, via della Tecnica 33 – 40050 Argelato (BO) Italy
Web site www.aev.eu e-mail info@aev.eu
4
Contents
Guarantee............................................................... 2
Technical Support .......................................................2
Factory Service and Repairs .............................................2
Shipping Instruction ....................................................2
Precautions .............................................................3
Contents ................................................................4
Features ................................................................5
Input functions and channels ............................................5
Input channel configuration .............................................5
Input setting ...........................................................5
Master outputs...........................................................6
External controls .......................................................6
Monitoring ..............................................................6
Front panel .............................................................6
Micro - Line channel ....................................................7
USB - Line Module .......................................................8
Telephone hybrid section ................................................9
Display & monitoring section............................................10
Control Room & Control Studio section ..................................10
Monitoring & service section ...........................................10
Master setup section ...................................................11
Rear Panel – Connections ...............................................12
Microphone input connections ...........................................12
Stereo line input connections ..........................................12
Auxiliary outputs connections ..........................................12
Master outputs connections .............................................13
Telephone lines connections ............................................13
Head/USB/Logic & PWS connections .......................................13
Logic I/O pinout .......................................................13
Technical specifications ...............................................14

AEV BSM Evolution USB Specifications

Microphone Inputs

input impedance	200 Ω
sensitivity level range	-70 ÷-40 dBu
maximum input level	- 30 dBu

Line Inputs

input impedance	10 K Ω
input level range	±12 dBu
headroom	+ 18 dBu

Telephone Hybrid

input impedance	600 Ω
tx level	±12 dBu
frequency response	300 Hz ÷ 3400 Hz (-2 dB)

Analog Outputs

output impedance	100 Ω
pgm output level range	-12 ÷ +12 dBu
utl/aux output level range	-12 ÷ +12 dBu

Headphones

output impedance	50 Ω
connector	JACK 6, 3 mm
configuration type	Stereo unbalanced

Logic I/O

max voltage	50 Vdc/ac
max current	100 mA
connector	DSUB 15 pole female

Physical Specifications

dimensions	484 x 310 x 45 mm
weight	5 Kg
usb port	2 x USB 2.0 interface
