Afikim PRS4024a User Manual

5/21
Introduction
This manual describes how to assemble the canopy roof for AfiKim Breeze-S3 and Breeze-S4
scooters.
The assembled canopy is possible on a chassis jig or a Breeze-S3/4
When assembling directly onto a Breeze-S3/4:
A. Part A: Disassembling the Front and Battery Covers. (Page 6)
B. Part B: Mounting the Inner Bracket. (Page 7)
C. Part C: Assembling the Rear Frame. (Page 9)
D. Part D: Returning the Front Cover to Scooter. (page 10)
Assembly steps:
1. Part 1: Assembling the Bottom Beam. (page 11)
2. Part 2: Assembling the Top Beam. (page 12)
3. Part 3: Assembling the Side Beams. (page 13)
4. Part 4: Assembling the Plastic Sheet. (page 14  17)
5. Part 5: Assembling the Side Panels. (page 18  19)
6. Part 6: Top Beam Assembly to the Rear Frame. (page 20)

Afikim PRS4024a Specifications

General

Brand	Afikim
Model	PRS4024a
Category	Scooter
Language	English
