Operation
16
4.Operation
4.1 Control Panel
1
3
5
2
4
UP
DOWN
ESC
ENT
6
POWER FAULTCOM
IItteemmssNNoo.. IItteemmssNNoo..
1
2
3
4
5
6
LCD Display
FAULT LED Indicator
COM LED Indicator
ESC Touch Button
UP Touch Button
DOWN Touch Button
ENT Touch Button
POWER LED Indicator
Grid
Load
PV Inverter
PV Inverter
PV Inverter
Distribu�on Cabinet
L1
L1‘
L2’
L3’
L2
L3
PV Array
RS485 / WiFi / Ethernet / GPRS
Afore Smart Meter
PV Array
PV Array
Router
Cloud Server
Weather Sta�on
Energy Meter
Note:
The Inverter could be connected in parallel with Smart Meter,
make sure the total load power not exceed Smart Mater’s limitation.
