PLINTH SPACERS
Fig. 10.1
DESN 517427
DESN 517793
DESN 516860
16.5 mm gap
Plinth base
Hotcupboard
Plinth base
FOR AGA R7/eR7 with
hotcupboard + MODULE ONLY
DESN 516852
FOR AGA R7/eR7 +
MODULE ONLY
DESN 516858
FOR AGA R7/eR7
with Hotcupboard +
MODULE ONLY
DESN 516276
Fig. 10.2
FOR AGA R7/eR7 + MODULE ONLY
11mm height
dierential
Plinth base
+1
-0
Fig. 10.3
Fig. 10.4
Fig. 10.5
Fig. 10.6
11mm height
dierential
+1
-0
