GENERAL INFORMATION
Thank you for buying the LT300! Although it is very simple to use, we
recommend that you read this manual before operating the laser.
Description
The LT300 is a visible laser that can be used for leveling, vertical alignment
& squaring. It’s totally waterproof and also has scanning and constant
squaring for interior jobs. Other advanced features include: totally automatic
self-leveling in both horizontal and vertical modes; electronic calibration by
the user; and optional remote control.
Specifications
Recommended use 1,000 ft. (300 m) diameter
Accuracy ± 1/8" @ 100 ft. (± 3 mm @ 30 m)
Self-leveling range ± 8%
Rotation speeds 0, 90, 150, 300, 450, 600 rpm
Scanning lengths From 2 to 35°
Slope match 5° on both X & Y axis; also, semi-automatic mode
with Y in manual, X in automatic
Laser battery NiCad rechargeable
Charging time 15 hours
Battery life 40 hours
Operating temperature 14˚ to 122˚ F (-10˚C to 50˚C)
Dimensions 5” x 4 1/2” x 8 1/2”
(12.5 x 11.5 x 21.9 cm)
Weight 7 3/4 lbs. (3.5 kg)
Environmental IP67
Laser diode 635 nm, visible, <5mW
IE
C/CDRH: Class 3R
Caution/Certification Label
Class 3R Laser Product
Wave length 630-680 nm
Max. Output Power 5mW
Laser Light: Avoid direct eye exposure
Conforms to IEC 60825-1; 2001
Complies with 21 CFR 1040.10 and 1040.11 except for deviations
Pursuant to Laser Notice No. 50
Dated July 26, 2001
