CHAPTER 2
6 AGCO RoGator RG900/1100/1300 Hawkeye™ Installation Manual
1. Check Hawkeye kit contents. See the Kit Contents section on page 7.
2. Replace existing strainer with an 80 mesh (or finer) strainer for use with the Hawkeye nozzle control system.
See the Hawkeye Installation Preparation section on page 7.
3. Remove spray tips and flush each section individually for a minimum of 20 seconds to thoroughly flush the
boom.
4. Mount Hawkeye nozzle control valves. See the Hawkeye Nozzle Control Valve Installation section on page 8.
5. Route and connect the secondary and primary boom cables. See the Boom Cable Routing and Connection
section on page 10.
6. Mount the Hawkeye product controller II ECU. See the Product Controller II ECU Installation section on page 13.
7. Route and connect chassis cable. See the Chassis Cable Routing and Connection section on page 19.
REQUIRED COMPONENTS
The following components must be installed with the Hawkeye nozzle control system:
• Updated software on field computers or control monitors. Contact your local RoGator dealer for the latest
version of C1000 software.
• PWM pump control valve
• Raven compatible flow meter
• Raven compatible pressure transducer
• 80 mesh (or finer) strainer
NOTE: Do not use air induction tips with the Hawkeye nozzle control system. A fan or cone style spray tip is
required for the Hawkeye system to operate properly.
TOOLS AND MATERIALS NEEDED
The following tools are recommended for completing the installation:
• SAE and metric sized wrenches and tools
•1-1/2” hole saw
• Drill bit set and drill
• Dielectric grease (supplied)
• Cable ties (supplied)
POINT OF REFERENCE
The instructions provided in this manual assume the installer is standing behind the machine, looking toward the
machine cabin.
