20
2313B EN 20041109
Introducing the CR User Station
CR USER STATION
Before inserting the identified cassettes in the Digitizer, they must be turned
90° so that the locking mechanism is at the bottom. The black tube side is
still pointed to the left:
Some cassettes will be inserted in the ID Tablet in the same manner as they
are dropped into the Digitizer:
35x43
35x35
24x30
10x12”
18x24
8x10”
Locking mechanism
24x30
mammo
18x24
mammo
15x30
Locking mechanism
