Introducing the CR User Station
CR USER STATION
Equipment for the CR Operator
Console
The CR User Station offers enough space in the two levels to insert a PC
(Server or Client), a Switch 10/100 Mbit with 8 or 16 plugs, an UPS for the
PC, and the transformer:
General instructions
The CR User Station and the equipment will be installed and configured by
an Agfa service technician.
If you use non-AGFA equipment, make sure that the dimensions and
technical specifications are compatible with the CR User Station.
All equipment of the CR User Station must be connected to the transformer
(via UPS if available).
! * = not included, must be ordered separately.
Front side Back side
PC * (Server or Client)
Fuses
ID Tablet
Monitor arm
height
adjustment
UPS*
