Remarks for HF-emission and immunity
CR USER STATION
This device is intended for operation in the electromagnetic
environment given below. The user of the device should ensure
that it is used in such an environment.
Resistance to
Jamming Test
IEC 60601
Test Level
Level of
Agreement
Electromagnetic Environ-
ment Guidelines
Discharge of static
electricity in
accordance with
IEC 61000-4-2
+
6 kV contact
discharge
+
8 kV air discharge
+ 6 kV contact
discharge
+
8 kV air discharge
Floors should consist of wood,
concrete or ceramic tiles. The
relative humidity must be at
least 30%, if the floor is made of
synthetic material.
Fast transient
electrical
disturbance
variables / bursts in
accordance with
IEC 61000-4-4
+
2 kV for network
leads
+
1 kV for entry and
outlet leads
+ 2 kV for network
leads
+
1 kV for entry and
outlet leads
The quality of the voltage
supplied should correspond to a
typical commercial or clinical
environment.
Impulse voltages
(surges) in
accordance with
IEC 61000-4-5
+
1 kV push-pull
voltage
+
2 kV common
mode voltage
+
1 kV push-pull
voltage
+
2 kV common
mode voltage
The quality of the voltage
supplied should correspond to
that of a typical commercial or
clinical environment.
Voltage
breakthroughs,
short term
interruptions and
variations in the
voltage supplied in
accordance with
IEC 61000-4-11
•< 5% U
r
(> 95%
breakthrough of
U
r
) for ½ period
• 40% U
r
(> 60%
breakthrough of
U
r
) for 5 periods
• 70% U
r
(30%
breakthrough of
U
r
) for 25 periods
•< 5% U
r
(95%
breakthrough of
U
r
) for 5 s
•< 5% U
r
(> 95%
breakthrough of
U
r
) for ½ period
•40% U
r
(> 60%
breakthrough of
U
r
) for 5 periods
•70% U
r
(30%
breakthrough of
U
r
) for 25 periods
•< 5% U
r
(95%
breakthrough of
U
r
) for 5 s
The quality of the voltage supply
should correspond to that of a
typical commercial or clinical
environment.
If the user wants the device to
work continuously, even when
the energy supply is interrupted,
it is recommended to use an
energy supply free of
interruptions or a battery.
Magnetic field at
the supply
frequency (50/60
Hz) in accordance
with IEC 61000-4-8
3 A/m 3 A/m
Magnetic field at the network
frequency should correspond to
the typical values as they are in
a commercial and clinical
environment.
• REMARK : U
r
is the alternating current in the network before the application of the test level.
