Capacitor Kit d-lab.1
AGFA d-lab.1 CM+9.8072.9003.0/DD+18070312D0/PN04073_00 7
3.5 Replacement of the capacitors
3.5.1 Removal of the LCD driver board
Remove the side cover of the print engine
Remove both connectors
