Capacitor Kit d-lab.1
AGFA d-lab.1 CM+9.8072.9003.0/DD+18070312D0/PN04073_00 9
Open the 4 screws of the plugs
From now on please wear the ESD wrist band!
Æ now it is possible to remove the LCD driver board.
