DX-D 100 Mobile X-ray Unit
User Manual
0188K EN 20201116
25
Illustration 2-3
Distribution of Stray Radiation on Chest Unit or Front Panel
HEIGHT ABOVE FLOOR (cm)
STRAY RADIATION (μGy/h)
0
20
40
60
80
100
120
140
160
180
200
0 500 1000 1500 2000 2500 3000 3500 4000 4500 5000 5500 6000 6500
S1
1
S1
2
S2
1
S2
2
d=50cm
d = 100 cm
d=50cm
d = 100 cm
d
SID 100 cm
X--Ray Receptor
Patient Support
Wall
Protective Device
CHEST UNIT
Phantom
S1
S2
Focal Spot
SIGNIFICANT ZONE OF OCCUPANCY
AT THE LEFT SIDE OF THE CHEST UNIT
SIGNIFICANT ZONE OF OCCUPANCY
AT THE RIGHT SIDE OF THE CHEST UNIT
d
MOBILE X--RAY UNIT
