AGFA DX-D 100 - Page 34

DX-D 100 Mobile X-ray Unit
User Manual
26
0188K EN 20201116
Illustration 2-4
Distribution of Stray Radiation on any Patient Support or any Ta ble
STRAY RADIATION (μGy/h)
HEIGHT ABOVE FLOOR (cm)
0
20
40
60
80
100
120
140
160
180
200
0 500 1000 1500 2000 2500 3000 3500 4000 4500 5000 5500 6000 6500 7000 7500 8000 8500 9000 950010000
S3
1
S3
2
S4
1
S4
2
d=50cm
d = 100 cm
d=50cm
d = 100 cm
S5
1
S5
2
d=50cm
d = 100 cm
d
d
d
MOBILE X--RAY UNIT
SIGNIFICANT ZONE OF OCCUPANCY
AT FRONT SIDE OF THE MOBILE UNIT
SIGNIFICANT ZONE OF OCCUPANCY
AT THE LEFT SIDE OF THE MOBILE UNIT
(ANODE)
SIGNIFICANT ZONE OF OCCUPANCY
AT THE RIGHT SIDE OF THE MOBILE UNIT
(CATHODE)
RAD TABLE
S3
S4
S5
Focal Spot
