DX-D 100 Mobile X-ray Unit
User Manual
0188K EN 20201116
63
3.11 DR DETECTOR
3.11.1 CONFIGURATION FOR WIRELESS DR DETECTORS
Wireless DR Detectors are placed in the Storage Bin at the Back Cover (for
Detectors, Grid and Accessories).
Wireless DR Detectors c ommunicate with the Mobile Unit through an internal
Wireless Access Point.
Storage Bin for Wireless DR Detectors,
Grid and Accessories (Font Cover)
Support for optional
Battery Charger and Grid
Wireless DR Detector
1
2
3
1
2
3
2
