AGFA MSC 100 - Page 42

Filmlauf / Film Drive / Avance film
AGFA MSC 200 / MSC 100
16.06.99 /PN 8043
3.7
FD Filmlauf-Rahmen 2 / FD Mainframe 2 / FD Châssis 2 8.8508.1200.0
Pos. Teil-Nr. ABC Bezeichnung Bemerkungen
Item no. Part no. Code Description Remarks
Pos. No. de ref. Désignation Remarques
1 9.8506.9220.2
Q1OR5 FD SM Power Drive Karte GS9
FD SM Power Drive PCB assy GS9
FD SM Power Drive carte GS9
2B 7.0426.6356.0
LED 2V / 20mA
LED 2V / 20mA
LED 2V / 20mA
2A 7.0426.6354.0
Meldeleuchte
Pilot lamp
Lampe de signalisation
2 9.8506.9340.0
Q1OUC ON/OFF Switchboard-Karte GS3
ON/OFF Switchboard PCB assy GS3
ON/OFF Switchboard carte GS3
3 9.8506.9270.1
Q1QVN Logik Distributor Karte GS2
Logic Distributor PCB assy GS2
Logik Distributor carte GS2
4 9.8506.9200.6
Q1QXR Drive Sensor PCB Assy GS10
Drive Sensor Gedruckte Schaltung GS10
Drive Capteur Circuit imprimè GS10
5 9.8506.2010.0
1BODE Ventilator komplett FA1
Fan assy FA1
Ventilateur complet FA1
6A 9.8506.9390.6
TKNY1 E-Prom V9.0 für Power Drive Control Ver I
E-Prom V9.0 for Power Drive Control Ver I
E-Prom V9.0 Power Drive Control Ver I
6 9.8506.9400.8
Power Drive Control prog. Ver 1 Gedruckteschaltung SK1
Power Drive Control pro. Ver 1 PCB Assy SK1
Power Drive Control prog. Ver 1 Circuit imprimè SK1
7 9.8506.9140.2
Q1Q1X Risc IO Karte SK2
Risc IO PCB assy SK2
Risc IO Circuit imprimè SK2
8 9.8506.9590.0
Q1Q2Z SK RISC Controller CF programmiert GS1 CF
RISC Controller CF Programmed GS1 CF
RISC Controlleur Circuit Imprimè GS1 CF
8A 9.8506.9580.0
1C7DT E-Prom für Risc CF Controller
E-Prom for Risc CF Controller
E-Prom pour Risc CF Controller
9 9.8506.9130.1
Motherboard Filmlauf Karte GS11
Motherboard Film Drive PCB assy GS11
Motherboard Avance film circuit imprimè GS11
10 9.8506.9260.2
Q1Q8D Power Distributor Gedruckte Schaltung GS1
Power Distributor PCB assy GS1
Power Distributor Circuit imprimè GS1
11 9.8506.8330.0
Kabel 750mm VS 46 - KA 15 - VS 45
Cable 750mm VS 46 - KA 15 - VS 45
Câble 750mm VS 46 - KA 15 - VS 45
12 9.8506.2150.1
Displayträger vollst.
Display holder assy
Support afficheur complet
13A TYPE 8508/13
1 Langsamer Spiegelschacht
Slow Mirrobox
Boite lent à miroir
13 TYPE 8508/130
Schneller Spiegelschacht
Fast Mirrorbox
Vite Boite a miroir
14 9.8506.2500.0
1JLYX Abschaltfilter-Einheit vollständig
Cut-Off Filter unit assy
Filtre de fin de pose complet
15 9.8506.2200.1
QZTM7 PC-Träger montiert
PC-Rack assy
PC-rack montè
16 9.8506.8020.0
Kabel 290mm VS 2 - KA 1 -
Cable 290mm VS 2 - KA 1 -
Câble 290mm VS 2 - KA 1 -
