AGFA MSC 100 - Verschlauchungsplan; Tube Arrangement; Plan de Tuyauterie

Papierprozessor / Paper Processor / Développeuse papier
AGFA MSC 100
28.07.99 /PN 8042
5.89
Verschlauchungsplan / Tube Arrangement / Plan de tuyauterie
Pos. Teil-Nr. ABC Bezeichnung Bemerkungen
Item no. Part no. Code Description Remarks
Pos. No. de ref. Désignation Remarques
1 P4 -86603
Schlauch
Tube
Tuyau flexible
2 P4 -86604 QTPL7
Schlauch
Tube
Tuyau flexible
3 P4 -86605
Schlauch
Tube
Tuyau flexible
4 P4 -86606
Schlauch
Tube
Tuyau flexible
5 P4 -86607
Schlauch
Tube
Tuyau flexible
6 P4 -86608
Schlauch
Tube
Tuyau flexible
7 P4 -86609
Schlauch
Tube
Tuyau flexible
8 P4 -86610
Schlauch
Tube
Tuyau flexible
9 P4 -86611
Schlauch
Tube
Tuyau flexible
10 P4 -86612
Schlauch
Tube
Tuyau flexible
11 P4 -86613
Schlauch
Tube
Tuyau flexible
12 P4 -86614
Schlauch
Tube
Tuyau flexible
13 P4 -86615
Schlauch
Tube
Tuyau flexible
14 P4 -86616 QTPMA
Schlauch
Tube
Tuyau flexible
15 P4 -86617
Schlauch
Tube
Tuyau flexible
16 P4 -86618
Schlauch
Tube
Tuyau flexible
17 P4 -86619 QTPNC
Schlauch
Tube
Tuyau flexible
18 P4 -86620
Schlauch
Tube
Tuyau flexible
19 P4 -86621
Schlauch
Tube
Tuyau flexible
20 P4 -86622
Schlauch
Tube
Tuyau flexible
21 P4 -86623
Schlauch
Tube
Tuyau flexible
