AGFA MSC 100 - Page 46

Filmlauf / Film Drive / Avance film
AGFA MSC 200 / MSC 100
16.06.99 /PN 8043
3.11
FD Filmlauf-Rahmen 2 / FD Mainframe 2 / FD Châssis 2 8.8508.1200.0
Pos. Teil-Nr. ABC Bezeichnung Bemerkungen
Item no. Part no. Code Description Remarks
Pos. No. de ref. Désignation Remarques
38 9.8506.8035.0
Kabel 460mm VS 7 - KA 4 - VS 8
Cable 460mm VS 7 - KA 4 - VS 8
Câble 460mm VS 7 - KA 4 - VS 8
39 9.8506.8030.0
Q28VX Kabel 240mm VS 5 - KA 3 - VS 6
Cable 240mm VS 5 - KA 3 - VS 6
Câble 240mm VS 5 - KA 3 - VS 6
40 9.8506.8185.3
Flachbandkabel VS 150 - VS 155 - FK 8 - VS 39, 14
Flat Cable VS 150 - VS 155 - FK 8 - VS 39, 14
Câble flat VS 150 - VS 155 - FK 8 - VS 39, 14
41 9.8506.8580.1
Q1WMT Kabel zur Reflektoreinheit CN3
Cable to lamp holder CN3
Câble de lampe CN3
45 7.0426.6339.0
836ZF 2-fach Interlock-Taste
Interlock Switch
Commutateur Interlock
46 9.8506.8215.3
Q3JU7 Kabel VS 62 - FK 14 - VS 160
Cable VS 62 - FK 14 - VS 160
Câble VS 62 - FK 14 - VS 160
47 9.8506.8255.1
Q1WOX Kabel FK31 VS 161 - FK 31 - VS 162
Cabel FK31 VS 161 - FK 31 - VS 162
Câble FK31 VS 161 - FK 31 - VS 162
47A 9.8506.9760.
0 Kabel 200mm ( vor APS ) VS159-VS160
Cable 200mm ( befor APS ) VS159-VS160
Câble 200mm ( avant APS) VS159-VS160
48 9.8506.2002.4
Q1WPZ Berührungsschutzplatte
Protection Plate
Plaque de securite
49 9.8506.8090.0
Q3FBR Kabel VS 167 - KA 33 - VS 168
Cable VS 167 - KA 33 - VS 168
Câble VS 167 - KA 33 - VS 168
50 9.8506.8040.0
Q28WZ Kabel 830mm VS 9 - KA 5 - VS 10
Cable 830mm VS 9 - KA 5 - VS 10
Câble 830mm VS 9 - KA 5 - VS 10
51 9.8506.8080.0
Q3E4A Kabel 500mm VS 13 - KA 26 -
Cable 500mm VS 13 - KA 26 -
Câble 500mm VS 13 - KA 26 -
52 9.8506.8260.0
Kabel VS 163 - FK 32 - VS 164
Cabel VS 163 - FK 32 - VS 164
Câble VS 163 - FK 32 - VS 164
53A 9.8506.9070.
3 E-Prom V9.31 für Power Drive Control Ver II
E-Prom V9.31 for Power Drive Control Ver II
E-Prom V9.31
53 9.8506.9680.0
Power Drive Control prog. Ver 2 Gedruckte Schaltung SK1
Power Drive Control pro. Ver 2 PCB Assy SK1
Power Drive Control prog. Ver 2 Circuit imprimè SK1
N4901 6.0227.520.
00 UA3J8 Scheibe DIN9021-3,2-A4
Washer DIN9021-3,2-A4
Rondelle DIN9021-3,2-A4
N2794 6.0215.015
.00 TAHQR Sechskantschrauben DIN933-M5x35-A4
Hexagon head screw DIN933-M5x35-A4
Vis hexagonale DIN933-M5x35-A4
N2970 7.0239.616
.24 UCQKC Linsensenkschraube mit Kreuzschlitz DIN966-M3x6-4.8
Cross recessed countersunk head screw DIN966-M3x6-4.8
Vis à tête fraisèe bombèe à fente crucif DIN966-M3x6-4.8
N4896 7.0227.518
.24 Scheibe DIN9021-5,3-St-Zn
Washer DIN9021-5,3-St-Zn
Rondelle DIN9021-5,3-St-Zn
N4180 7.0224.307
.24 Linsensenkschraube mit Kreuzschlitz DIN7982-ST3,5x6,5-F-H-STZn
Cross recessed cheese head screw DIN7982-ST3,5x6,5-F-H-STZn
Vis à tète fraisèe bombèe à fente cruciforme DIN7982-ST3,5x6,5-F-H-STn
N2340 7.0213.889
.24 UCFGX Zylinderschraube mit Innensechskant DIN912-M5x16-8.8-Zn
Hexagon socket cheese head screw DIN912-M5x16-8.8-Zn
Vis cylindrique à six pans DIN912-M5x16-8.8-Zn
