36 HDR-DAD Solution
4 Using the HDR-DAD Solution
Status Information and Module Information Dialog of the HDR-DAD Cluster
• The module information dialog shows information about the access point
and the additional 2
nd
LAN connection of the HDR-DAD cluster.
Figure 13 Information on Additional Connection and Access Point
