64
Chapter 2 Front-Panel Menu Operation
To Store the Instrument State
2
• To delete a character, rotate the knob until you get to the blank
character before the capital A.
• To delete all characters from the cursor position to the end of the line,
press teh +/- key.
• To use numbers in the name, you can enter them directly from the
numeric keypad.
3 Store the instrument state.
Press the STORE STATE softkey. A stored state contains the selected
function, frequency, amplitude, DC offset, duty cycle, symmetry, as well
as any modulation parameters in use. The instrument does not store
volatile waveforms created in the arbitrary waveform function.
4 Recall the instrument state (optional).
If at some later time you wish to restore (retrieve) a stored state, press
and then Store / Recall. Then press Recall State, select the state
to recall and press Select.
