34410A/11A/L4411A Service Guide 65

Calibration Procedures 3

[1] Select 100 NPLC.

[2] Specifications are for 4

–wire Ohms function or 2–wire Ohms function using math null. Without

math null, add 0.2 Ω additional error in the 2

–wire Ohm function.

Q: Quick performance verification test points.

Quick

Check

Error from Nominal

Input Function

[1]

Range 24 hour 90 day 1 year

Open DC Current 100 μA ± 0.02 µA ± 0.025 µA ± 0.025 µA

Open 1 mA ± 0.060 µA ± 0.060 µA ± 0.060 µA

Open 10 mA ± 2 µA ± 2 µA ± 2 µA

Open 100 mA Q ± 4 µA ± 5 µA ± 5 µA

Open 1 A ± 60 µA ± 100 µA ± 100 µA

Open 3 A ± 600 µA ± 600 µA ± 600 µA

Short DC Volts 100 mV Q ± 3 µV ± 3.5 µV ± 3.5 µV

Short 1 V ± 6 µV ± 7 µV ± 7 µV

Short 10 V ± 40 µV ± 50 µV ± 50 µV

Short 100 V ± 600 µV ± 600 µV ± 600 µV

Short 1000 V ± 6 mV ± 6 mV ± 6mV

Short 4–Wire Ohms

[2]

100 Ω ± 3 mΩ ± 4 mΩ ± 4 mΩ

Short 1 kΩ ± 5 mΩ ± 10 mΩ ± 10 mΩ

Short 10 kΩ Q ± 50 mΩ ± 100 mΩ ± 100 mΩ

Short 100 kΩ ± 500 mΩ ± 1 Ω ± 1 Ω

Short 1 MΩ ± 10 Ω ± 10 Ω ± 10 Ω

Short 10 MΩ ± 100 Ω ± 100 Ω ± 100 Ω

Short 100 MΩ ± 1 kΩ ± 1 kΩ ± 1 kΩ
