30 34410A/11A/L4411A Service Guide
1 Specifications
Data From Memory
Maximum reading rate out of memory
(Sample count 50000, trigger count 1, "FETC?" or "R?")
General Specifications (34410A/11A)
Power Supply: 100V/120V/ 220V / 240V ± 10%
Power Line Frequency: 50–60 Hz ± 10%,
400 Hz ± 10%.
Automatically sensed at power–on, 400 Hz defaults to 50Hz.
Power Consumption: 34410A/34411A: 25 VA peak ( 16 W average )
L4411A: 50 VA peak (18 W average)
Operating Environment: Full accuracy for 0 °C to 55 °C
Full accuracy to 80% R.H. at 40
o
C Non–condensing
Storage Temperature –40 °C to 70 °C
Operating Altitude Up to 3000m
Rack Dimensions (WxHxD):212.8mm x 88.3mm x 272.3mm (34410A/11A)
Bench Dimensions (WxHxD):261.2mm x 103.8mm x 303.2mm (34410A/11A)
Weight: 3.72 kg (8.2 lbs) 3410A/11A
Safety: IEC 61010-1
EN 61010-1
UL 61010-1
CAN/CSA-C22.2 No. 61010-1
Refer to Declaration of Conformity for current revisions.
Measurement CAT II 300V, CAT I 1000V
Pollution Degree 2
EMC: IEC 61326
EN 61326
CISPR 11
ICES-001
AS/NZS 2064.1
Refer to Declaration of Conformity for current revisions.
Acoustic Noise 37 dBa
Display: Dual–line, 17–segment vacuum florescent display (34410A/34411A)
State Storage Memory Power Off state automatically saved, 4 User Configurable Stored States
Readings GPIB
rdg/Sec
USB 2.0
rdg/Sec
LAN (VXI-11)
rgs/Sec
LAN (Sockets)
rdg/Sec
ASCII 4000 8500 7000 8500
4–byte Binary 89,000 265,000 110,000 270,000
8–byte Binary 47,000 154,000 60,000 160,000
