Using the Oscilloscope

To install the printer software

3-68

21 Optional — Make sure that your printer is powered on.

22 Click Yes to print a test page. Then click Finish.

The oscilloscope sends the printer test page and displays the Test Page

Complete dialog.

Figure 3-52

Test Page Complete

23 If the page printed successfully, click Yes.

If you have a problem with the printer, see the section “When Something Goes

Wrong” in the built-in information system. See chapter 4 for more information

on accessing and using the built-in information system.

You Must Now Cycle Power

You must now cycle power on the scope to have your new printer setup take effect.
