Setting Up the Oscilloscope
To connect power
1-8
To connect power
1 Position the oscilloscope where it will have sufficient clearance for
airflow around the top, back, and sides.
Figure 1-2
Positioning the Infiniium Oscilloscope with Sufficient Clearance
Minimum 0 mm
Minimum 15.9 mm
both sides
Minimum 38.1 mm
Airflow requirements
54810A-25A 125 cfm
54835A-45A 250 cfm
Minimum 15.9 mm
