Setting Up the Oscilloscope
To connect an GPIB cable
1-25
To connect an GPIB cable
1 Attach the GPIB connector to the GPIB interface card connector at the
rear of the oscilloscope.
2 Tighten the thumbscrews on the connector.
Figure 1-20
Attaching the GPIB Connector
