Using the Oscilloscope

To start and stop waveform acquisition

3-37

To start and stop waveform acquisition

• To start waveform acquisition, click the start button at the bottom of

the waveform display area.

• To stop waveform acquisition, click the stop button at the bottom of

the waveform display area.

See figure 3-25.

You can still use the Run and Stop keys on the front panel while the graphical

interface is enabled. However, if you are performing many graphical interface

operations, it is easier to start and stop the oscilloscope using the buttons in the

interface, so you do not have to remove your hand from the mouse.

Figure 3-25

Start and Stop Icons

Click this button

to stop waveform

acquisition

Click this button

to start waveform

acquisition
