Site Preparation
Site Preparation Guide 21
Table 2 Product dimensions
Approximate Dimensions, cm (in)
Product Height Width Depth Weight, kg (lb)
5975 Series MSD
• G3170A Diffusion EI MSD 41 (16) 30 (12) 54 (21) 39 (85)
• G3171A Standard turbo EI MSD 41 (16) 30 (12) 54 (21) 39 (85)
• G3172A Performance turbo EI MSD 41 (16) 30 (12) 54 (21) 41 (90)
• G3174A EI/PCI/NCI MSD 41 (16) 30 (12) 54 (21) 46 (100)
7890 Series GC 54 (21) 59 (23) 54 (21) 50 (112)
6890 Series GC 50 (20) 58 (23) 55 (22) 50 (110)
6850 Series GC 50 (20) 29 (11) 54 (21) 23 (51)
Data System Data system size and weight depend on the components included in the data
system. Reserve at least 100 cm (39 in) of bench space for the data system. A
typical data system weight is 34 kg (75 lb).
Be sure to allow space for your carrier and reagent gases.
NOTE
The values in Table 2 are for a single MSD ChemStation configuration. Two-MSD
configurations require additional table space. The second GC/MSD system can be located
on a different table and connected to the ChemStation with a network cable.
