Performance Test Record - Agilent 6031A POWER SUPPLY (Page 2 of 2)
MODEL Agilent 6031A
Report No.______________ Date_____________________
Page
No.
Test Description
Minimum Spec. Results
*
Maximum
Spec.
Measurement
Uncertainty
Constant Voltage Tests
23 Voltage Programming
and Readback
Low Voltage (0.10V)
Front Panel Display
GPIB Readback
0.085
V
OUT
- 0.007
V
OUT
- 0.007
________V
________V
________V
0.115
V
OUT
+ 0.007
V
OUT
+ 0.007
3
µV
3
µV
3
µV
High Voltage (20.0V)
Front Panel Display
GPIB Readback
19.978
V
OUT
- 0.028
V
OUT
- 0.023
________V
________V
________V
20.022
V
OUT
+ 0.028
V
OUT
+ 0.023
335
µV
335
µV
335
µV
23 Load Effect (7.0V)
V
OUT
- 0.0037 _______mV V
OUT
+ 0.0037 1µV
24 Source Effect (20.0V)
V
OUT
- 0.004 _______mV V
OUT
+ 0.004 20µV
25
26
PARD (Ripple and Noise)
RMS
Peak-to-Peak
0
0
_______mV
_______mV
0.008
0.050
1.2mV
1.5mV
27 Transient Recovery
(90% to 100% Full Load)
0 _______mV 0.100/2ms 12mV
Constant Current Tests
28 Current Programming
and Readback
Low Current (0.50A)
Front Panel Display
GPIB Readback
0.248
I
OUT
- 0.303
I
OUT
- 0.102
________A
________A
________A
0.751
I
OUT
+ 0.303
I
OUT
+ 0.102
220
µA
220
µA
220
µA
High Current (120A)
Front Panel Display
GPIB Readback
119.450
I
OUT
- 1.140
I
OUT
- 0.580
________A
________A
________A
120.550
I
OUT
+ 1.140
I
OUT
+ 0.580
50mA
50mA
50mA
29 Load Effect (50.0A)
I
OUT
- 0.020 ________mA I
OUT
+ 0.020 25µA
29 Source Effect (120A)
I
OUT
- 0.037 ________mA I
OUT
+ 0.037 136mA
30 PARD (Ripple and Noise)
0 ________mA 0.120 18mA
