Replaceable Parts
Introduction
This chapter contains information for ordering replacement parts. Table 5-1 lists parts in alpha-numeric order by reference
designators and provides the following information:
a.
Reference Designators. Refer to Table 5-1.
b.
Agilent Technologies model in which the particular part is used.
c.
Agilent Technologies Part Number.
d.
Description. Refer to Table 5-2 for abbreviations.
Parts not identified by reference designator are listed at the end of Table 5-4 under Mechanical and/or Miscellaneous.
Table 5-1. Reference Designators
A Assembly
BBlower
C Capacitor
CR Diode
DS Signaling Device (light)
FFuse
FL Filter
G Pulse Generator
J Jack
K Relay
L Inductor
Q Transistor
RT Thermistor Disc
S Switch
T Transformer
TB Terminal Block
TS Thermal Switch
U Integrated Circuit
VR Voltage Regulator (Zener diode)
W Wire Jumper)
XSocket*
Y Oscillator
* Reference designator following "X" (e.g. XA2) indicates assembly or device mounted in socket.
