Agilent Technologies 6032A User Manual

47
Table 3-4. Primary Processor Signature Table
(A8U6 = P/N 5080-2160 REV A.00.00, A.00.01, A.00.02 and A.00.04)
A.00.04 A.00.02 A.00.01 A.00.00
A(0) A46A A46A A46A A46A U16-12 U6-12 U8-12 U12-11 U17-21
A(1) 4148 UH8O UH8O UH8O U16-13 U6-11 U8-11 U12-13 U17-22
A(2) 72F5 82H5 UO39 4FU1 U16-14 U6-10 U8-10 U12-9 U17-23
A(3) PAU8 9899 HOPF 86C2 U16-15 U6-9 U8-9 U12-10
A(4) A4A7 3088 O7FA 5A37 U16-16 U6-8 U8-8 U12-8
A(5) 45OP 48H5 5823 PHHO U16-17 U6-7 U8-7
A(6) C3UU UF3H 2682 3F6U U16-18 U6-6 U8-6 U36-11
A(7) HOU4 HOU4 F6OP HFP3 U16-19 U6-5 U8-5 U36-9
A(8) 4U39 4U39 17AF 17AF U14-52 U6-27 U8-27 U36-8
A(9) 45A8 45A8 62H1 62H1 U14-51 U6-26 U8-26 U36-7
A(10) 278A 278A OOU3 OOU3 U14-50 U6-23 U8-23 U36-6
A(11) 6OA3 6OA3 6OA3 6OA3 U14-49 U6-25 U8-25 U36-5
A(12) 7826 7826 7826 7826 U14-48 U6-4 U8-4 U36-4
A(13) 5850 5850 5850 585O U14-47 U6-28 U8-28 U36-3
A(14) F93H F93H F93H F93H U14-46 U6-29 U8-3 U36-2
A(15) 79UA 79UA 79UA 79UA U14-45 U6-3 U8-31 U36-1
D(0) PH2F 48P2 48P2 48P2 U14-60 U16-9 U6-13 U8-13 U12-22 U17-12
D(1) HU9O 6O84 6O84 6O84 U14-59 U16-8 U6-14 U8-14 U12-21 U17-13
D(2) U665 74UH 96C5 HA6P U14-58 U16-7 U6-15 U8-15 U12-20 U17-14
D(3) 53PP 16A9 UH79 8OC2 U14-57 U16-6 U6-17 U8-17 U12-19 U17-15
D(4) C9C2 196F AA13 U64C U14-56 U16-5 U6-18 U8-18 U12-18 U17-16
D(5) C27C 132C 8A9F 89AP U14-55 U16-4 U6-19 U8-19 U12-17 U17-17
D(6) HO18 4387 497F 2C5F U14-54 U16-3 U6-20 U8-20 U12-16 U17-18
D(7) P97H 4FC3 33AO U44P U14-53 U16-2 U6-21 U8-21 U12-15 U17-19
WR* FP65 FP65 FP65 FP65 U14-40 U8-29 U36-12
RD* unstable 3PPH 3PPH 3PPH U14-61 U6-24 U8-24 U36-13
ALE U665 4OAP 4OAP 4OAP U14-62 U16-11
READY 26C3 26C3 26C3 26C3 U14-43 U36-15
BANK_SEL unstable 5AHH unstable unstable U14-27 U36-14
EE(0) 7CF1 7CF1 7CF1 7CF1 U14-19 U70-1
EE(1) AH32 AH32 AH32 AH32 U14-20 U70-2
EE(2) HCCH HCCH HCCH HCCH U14-21 U70-3
EE(3) 9P5F 9P5F 9P5F 9P5F U14-22 U704
APC 9361 9361 9361 9361 U14-23 U15-22
UART CHU5 CHU5 CHU5 CHU5 U12-14 U36-16
GPIB 2688 2688 2688 2688 U36-17 U17-8
ROM C95F C95F C95F C95F U6-22 U36-19
RAM 9UPU 9UPU 9UPU 9UPU U8-22 U36-18
