Agilent Technologies 6032A User Manual

49
Table 3-6. Front Panel Address Latches and Decoders
(A8U6 = P/N 5080-2160 REV A.00.00, A.00.01, A.00.02 and A.00.04 Inputs)
Inputs:
Node Measurements
U14-26 Toggling (unstable)
U14-35 37F8
U14-38 1ABC
U15-9, U17-3,6 Cycle power to unit--Lo to Hi after approx. 160 ms
U17-4,5 Cycle power to unit--Hi to Lo after approx. 160 ms
Outputs:
U13-1, U14-1, U15-3 969U U14-5, U16-6 F615 U16-5, U17-12 9C3C
U13-2, U14-2, U15-4 C7AA U14-13 Toggling U16-12, U17-8 4056
U13-3, U14-3, U15-5 A372 U14-14 5AHH U16-13, U17-10 Toggling
U13-4, U14-4, U17-11 Toggling U14-15 HU9C U17-1 37F8
U13-5, U16-3 5C91 U15-1, U17-2 6H15 U17-2
U13-6, U14-6, U17-9 1ABC U15-2 +5V
U13-7 8U73 U15-3
U13-9 5730 U15-6, U16-2, U17-3 FlP6
U13-10 PHFF U15-8, U16-11 P62F
U13-11 51U7 U15-10, U16-1,4,10 9H84
U13-12 AH52
U13-13 6F42
U13-14 50A9
U13-15 F05U
