Replaceable Parts 133
Table 5-11. A4A1/A4A3 Left Tunnel Board Parts for 500 Watt 655xA & 665xA Models (continued)
Reference
Desig.
Applicable Models Agilent Part No. Description
R209 0757-0280 Resistor 1K 1% .125W
R210 65/6651A, 65/6652A 0698-8959 Resistor 619K 1%
65/6653A-65/6655A 0757-0481 Resistor 475K 1%
R211 65/6651A, 65/6652A 0811-3849 Resistor .25 5% 3W
65/6653A 0811-3848 Resistor .39 5% 3W
65/6654A 0811-3847 Resistor .66 1% 3W
65/6655A 0811-1220 Resistor 1.5 5% 3W
R212 0757-0316 Resistor 42.2 1%
R213 0698-3441 Resistor 215 1% .125
R214 0698-0085 Resistor 2.61K 1%
R215 65/6651A-65/6654A 0698-3454 Resistor 215K 1%
6655 0757-0466 Resistor 110K 1%
R216 65/6651A, 65/6652A 0811-3849 Resistor .25K 5% 3W
65/6653A 0811-3848 Resistor .39 5% 3W
65/6654A 0811-3847 Resistor .66 1% 3W
65/6655A 0811-1220 Resistor 1.5 5% 3W
R217 65/6651A-65/6654A 0698-3430 Resistor 21.5 1%
65/6655A 8159-0005 Resistor 0 Ohms
R218 65/6651A-65/6654A 0698-3441 Resistor 215 1% .125W
6655 Not used
R219 0757-0280 Resistor 1K 1% .125W
R220 0698-3454 Resistor 215K 1%
R221 0757-0280 Resistor 1K 1% .125W
R223,224 0683-0475 Resistor 4.7 5% .25W
R225-228 65/6651A 0811-3849 Resistor .25 5% 3W
65/6652A-65/6655A Not used
R229, 230, 232 65/6651A-65/6654A Not used
65/6655A 0698-3430 Resistor 21.5 1%
U201,202 1826-0962 IC 412 comparator
1200-1158 Transistor socket (ref
Q201 ,203,205,207)
0340-0458 Insulator (ref Q205)
0515-0064 Screw-mach M3 x .5 16 m 19 pan
head (ref Q201, 203, 205, 207)
2190-0584 Washer-lk hlcl (ref Q201 ,203,205 ,207
