Agilent Technologies 654 A Series Service Manual

134 Replaceable Parts
Table 5-12. A4A2/A4A4 Right Tunnel Board Parts List for 500 Watt 655xA & 665xA Models
Reference
Desig.
Applicable Models Agilent Part No. Description
C301-304 0160 4801 Capacitor 100 pF 5%
C305,306 0160-4835 Capacitor luF 10% 50V
C307 0160-4801 Capacitor 100 PF 5%
C309 0160-6806 Capacitor luF 400V
F301-303 65/6641A-65/6645A 2110-0671 Fuse .125AM, 125V
F301-303 65/6651A-65/6655A 2110-0716 Fuse .5AM, 125V
F304-307 65/6651A 2110-0713 Fuse 10AM, 125V
65/6652A-65/6655A 8159-0005 Resistor 0 Ohms
J300 1251-4245 Conn 2-pin (ref therm assy RT301)
J301 1251-8184 Phone recept (control)
J302 1251-4781 Conn Util (power)
Q301 65/6651A-65/6654A 1854-0989 Transistor NPN SI
6655 1855-0840 MOSFET-N-Chan
Q302 65/6651A, 65/6652A 5060-3315 Assy (includes FET 1855-0725 and HS)
65/6653A, 65/6654A 5060-3314 Assy (includes FET 1855-0641and HS)
6655 Not used
Q303 65/6651A-65/6654A 1854-0989 Transistor NPN SI
65/6655A 1855-0840 MOSFET- N-Chan
Q304 65/6651A, 65/6652A 5060-3315 Assy (includes FET 1855-0725 and HS)
65/6653A,65/6654A 5060-3314 Assy (includes FET 1855-0641 and HS)
65/6655A Not used
Q305 65/6651A-65/6654A 1854-0989 Transistor NPN SI
6655 1855-0840 MOS-N-Chan
Q306 65/6651A, 65/6652A 5060-3315 Assy (includes FET 1855-0725 and HS)
65/6653A, 65/6654A 5060-3314 Assy (includes FET 1855-0641 and HS)
6655 Not used
Q307 65/6651A-65/6654A 1854-0989 Transistor NPN SI
65/6655A 1855-0840 MOSFET- N-Chan
Q308 65/6651A, 65/6652A 5060-3315 Assy (includes FET 1855-0725and HS)
65/6653A, 65/6654A 5060-3314 Assy (includes FET 1855-0641 and HS)
65/6655A Not used
R301 65/6651A, 65/6652A 0811-3849 Resistor .25 5% 3W
65/6653A 0811-3848 Resistor .39 5% 3W
65/6654A 0811-3847 Resistor .66 1% 3W
65/6655A 0811-1220 Resistor 1.5 5% 3W
R302 65/6651A-65/6654A 0698-3430 Resistor 21.5 1%
65/6655A 8159-0005 Resistor 0 Ohms
R303 65/6651A-65/6654A 0698-3441 Resistor 215 1% .125W
65/6655A Not used
R304 0757-0280 Resistor 1k 1% .125W
R305 65/6651A-65/6653A Not used
65/6654A, 65/6655A 0698-3459 Resistor 383K 1%
R306 65/6651A, 65/6652A 0811-3849 Resistor 0.25 5% 3W
65/6653A 0811-3848 Resistor 0.39 5% 3W
65/6654A 0811-3847 Resistor 0.661% 3W
65/6655A 0811-1220 Resistor 1.5 5% 3W
R307 65/6651A-65/6654A 0698-3430 Resistor 21.5 1%
65/6655A 8159-0005 Resistor 0 Ohms
R308 65/6651A-65/6654A 0698-3441 Resistor 215 1% .125W
65/6655A Not used
