Agilent Technologies 654 A Series Service Manual

132 Replaceable Parts
Table 5-11. A4A1/A4A3 Left Tunnel Board Parts for 500 Watt 655xA & 665xA Models
Reference
Desig.
Applicable Models Agilent Part No. Description
C20l-204 0160-4801 Capacitor 100pF 5% 100V
C205,206 0160-4835 Capacitor 0.luF 10% 50V
C207 0160-4801 Capacitor 100pF 5% 100V
C208, 209 0160-6806 Capacitor 0.luF 400V
C211 0160-4812 Capacitor 220pF 5%
D201 1901-1098 Diode IN4150
F201-204 65/6641A-65/6645A 2110-0671 Fuse .125AM, 125V
F201-204 65/6651A-65/6655A 2110-0716 Fuse .5AM, 125V
F205-207 6651A 2110-0713 Fuse submin 10AM, 125V
65/6652A-65/6655A 8159-0005 Resistor 0 Ohms
F208 8159-0005 Resistor 0 Ohms
J201 1251-8184 Phone recept (control sigs)
J202 1251-4781 Connector Util (power)
Q201 65/6651A-65/6654A 1854-0989 Transistor NPN SI
65/6655A 1855-0849 MOSFET- N - Chan
Q202 65/6651A, 65/6652A 5060-3315 Assy (includes FET 1855-0725 and HS)
65/6653A, 65/6654A 5060-3314 Assy (includes FET 1855-0641 and HS)
65/6655A Not used
Q203 65/6651A, 65/6654A 1854-0989 Transistor NPN SI
65/6655A 1855-0849 MOSFET- N - Chan
Q204 65/6651A-65/6654A 5060-3315 Assy (includes FET 1855-0725 and HS)
65/6653A, 65/6654A 5060-3314 Assy (includes FET 1855-0641 and HS)
65/6655A Not used
Q205 65/6651A-65/6654A 1854-0989 Transistor NPN SI
65/6655A 1854-1162 Transistor NPN SI
Q206 65/6651A, 65/6652A 5060-3231 Assy (includes XSTR 1853-0497 and HS)
65/6653A-65/6655A 5060-3250 Assy (includes XSTR 1853-0652 and HS)
Q207 65/6651A-65/6654A 1854-0989 Transistor NPN SI
65/6655A 1855-0849 MOSFET- N-Chan
Q208 65/6651A, 65/6652A 5060-3315 Assy (includes FET 1855-0725 and HS)
65/6653A, 65/6654A 5060-3314 Assy (includes FET 1853-0641 and HS)
65/6655A Not used
R201 65/6651A, 65/6652A 0811-3849 Resistor .25 5% 3W
65/6653A 0811-3848 Resistor .39 5% 3W
65/6654A 0811-3847 Resistor .66 1% 3W
65/6655A 0811-1220 Resistor 1.5 5% 3W
R202 65/6651A-65/6654A 0698-3430 Resistor 21.5 1%
65/6655A 8159-0005 Resistor 0 Ohms
R203 65/6651A-65/6654A 0698-3441 Resistor 215 1%
6655 Not used
R204 0757-0280 Resistor 1K 1% .125W
R205 Not used
R206 65/6651A, 65/6652A 0811-3849 Resistor .25 5% 3W
65/6653A 0811-3848 Resistor .39 5% 3W
65/6654A 0811-3487 Resistor .66 1% 3W
65/6655A 0811-1220 Resistor 1.5 5% 3W
R207 65/6651A-65/6654A 0698-3430 Resistor 21.5 1%
65/6655A 8159-0005 Resistor 0 Ohms
R208 65/6651A-65/6654A 0698-3441 Resistor 215 1% .125W
65/6655A Not used
